EXHAUST GAS PROCESSOR KT-HM-10/300M series

Product Introduction

This series of ozone destroyers KT-HM is suitable for water purification, sewage treatment, etc, The top of the ozone mixing tank and the reaction tank have ozone exhaust emissions, if they are directly discharged, a large amount of ozone will be contained in a wide range of spaces, which will make the staff uncomfortable, An ozone destroyer is installed behind the exhaust gas. After the discharged ozone gas enters the ozone destroyer, the gas that comes out becomes oxygen, which can also play a role in increasing oxygen.

Product composition

Stainless steel case, digital display control circuit board,temperature detection board, ozone destruction tube, thermocouple, roots blower, cooler, cooling fan, etc.

Product Features

(1) Using micro-gap discharge technology, microcomputer control motherboard, you can schedule scheduled shutdown

(2) infrared remote control function, easy to operate and quick to use

(3) Built-in temperature detection, perfect protection and alarm function

(4) The high-voltage transformer adopts high-quality A-grade magnetic core, with high magnetic flux and low heat generation, thereby reducing the power consumption of the whole machine

Scope of application

Water purification, swimming pool water aquaculture,aquarium,sewage treatment, etc, ozone mixing tank lops, protein separators, and reaction pools have ozone exhaust emissions.
